SPI_Extender
2 layer board of 0.80 x 0.82 inches (20.4 x 20.9 mm)
Uploaded:
April 28th 2021
Shared:
April 28th 2021
Total Price:
$3.30
Tap into the motor-driver SPI bus on BTT SKR boards (and maybe others, though SKR Pros would need a variant with the SPI header adjacent to pins 8 & 9).
https://gitlab.com/salfter/spi_extender contains both this version and a vertical version for the …
Show full description
Tap into the motor-driver SPI bus on BTT SKR boards (and maybe others, though SKR Pros would need a variant with the SPI header adjacent to pins 8 & 9).
https://gitlab.com/salfter/spi_extender contains both this version and a vertical version for the …
Show full description
TQFP-44 (0.8 mm) to DIP Adapter
2 layer board of 2.26 x 0.86 inches (57.3 x 21.7 mm)
Uploaded:
February 9th 2018
Shared:
February 9th 2018
Total Price:
$9.65
…because they're either not cheap to buy or cheap to ship. :)
KiCad PCB and Gerbers at https://gitlab.com/salfter/tqfp44-dip-adapter.
…because they're either not cheap to buy or cheap to ship. :)
KiCad PCB and Gerbers at https://gitlab.com/salfter/tqfp44-dip-adapter.
A2RPi_v2
2 layer board of 3.00 x 3.00 inches (76.2 x 76.2 mm)
Uploaded:
February 2nd 2018
Shared:
February 2nd 2018
Total Price:
$45.00
Apple II Raspberry Pi adapter
KiCad files at https://gitlab.com/salfter/A2RPi_v2
Apple II Raspberry Pi adapter
KiCad files at https://gitlab.com/salfter/A2RPi_v2
cdweld
2 layer board of 2.48 x 2.01 inches (63.0 x 51.0 mm)
Uploaded:
January 23rd 2018
Shared:
January 23rd 2018
Total Price:
$24.85
Capacitive-discharge welder, adapted from http://www.philpem.me.uk/elec/welder/
KiCad files at https://gitlab.com/salfter/cdweld
Specify 2 oz. copper when ordering
Capacitive-discharge welder, adapted from http://www.philpem.me.uk/elec/welder/
KiCad files at https://gitlab.com/salfter/cdweld
Specify 2 oz. copper when ordering
rgb2component
2 layer board of 1.81 x 3.39 inches (45.8 x 86.0 mm)
Uploaded:
July 13th 2014
Shared:
July 13th 2014
Total Price:
$30.50
