Cree LED star 3-up
2 layer board of 0.86 x 0.95 inches (21.7 x 24.1 mm)
Uploaded:
December 14th 2017
Shared:
December 14th 2017
Total Price:
$4.05
3-up star for Cree XP-G / XP-E (and other 3.45mm LEDs). Use Aluminum MCPCB for power >1W each!! Use 2x 0Ω 0805 resistors to close the circuit.
3-up star for Cree XP-G / XP-E (and other 3.45mm LEDs). Use Aluminum MCPCB for power >1W each!! Use 2x 0Ω 0805 resistors to close the circuit.
esp32 d2wd
4 layer board of 0.91 x 0.73 inches (23.0 x 18.6 mm)
Uploaded:
October 13th 2017
Shared:
October 13th 2017
Total Price:
$6.60
Prototyping board for esp32-d2wd. PCB antenna has not been tuned. <https://github.com/lbernstone/esp32-d2wd>
Prototyping board for esp32-d2wd. PCB antenna has not been tuned. <https://github.com/lbernstone/esp32-d2wd>
TPS54202
2 layer board of 0.95 x 0.42 inches (24.0 x 10.8 mm)
Uploaded:
June 16th 2017
Shared:
June 29th 2017
Total Price:
$2.00
3V3 DC/DC power supply using TPS54202. Kicad and BOM located at <https://github.com/lbernstone/TPS54202> .
3V3 DC/DC power supply using TPS54202. Kicad and BOM located at <https://github.com/lbernstone/TPS54202> .
